| Model | MS-WIF1D | MS-WIF2D | MS-WIF3D | MS-WIF4D | MS-WIF5D | MS-WIF6D | MS-WIF7D | MS-WIF8D | MS-WIF9D | MS-WIF10D | MS-WIF11D |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Exterior (D x W x H)(M) | 1.2*1.8*2.2 | 1.5*1.8*2.2 | 1.8*1.8*2.2 | 2*1.8*2.4 | 2*2*2.4 | 2.4*2.4*2.4 | 2.4*3*2.4 | 3*3*2.4 | 3*4*2.4 | 3*5*2.4 | 3*6*2.4 |
| Capacity(m³) | 3.2m³ | 4.2m³ | 5.1m³ | 6.3m³ | 7.1m³ | 10.6m³ | 13.3m³ | 17.2m³ | 23.4m³ | 29.6m³ | 35.7m³ |
| frequency conversion | Variable frequency | ||||||||||
| Doors | Swinger Solid | ||||||||||
| Compressor Location | Top or Front | ||||||||||
|
Refrigeration Type |
Self-Contained |
||||||||||
| Energy Consumption (KWhr/day) | 4.81KWH/24H | 4.81KWH/24H | 4.81KWH/24H | 4.81KWH/24H | 9.42KWH/24H | 9.42KWH/24H | 9.42KWH/24H | 13.7KWH/24H | 13.7KWH/24H | 19.5KWH/24H | 19.5KWH/24H |
| Electrical Power/ Current | 810W | 810W | 810W | 810W | 1570W | 1570W | 1570W | 2290W | 2290W | 3250W | 3250W |
| Number of Shelves /Type | Equipped separately | ||||||||||
| SPECIFICATION | CONTENT |
|---|---|
| rated voltage： | 220 V~240V / 50 Hz Customizable 110V~240V/50-60HZ |
| Power Plug/Cord Length | 16A、3M |
| Refrigerating system | Air-Cooling |
| Compressor brand | Cubigel Can be modified according to needs |
| Core Components | Refrigeration Units |
| Refrigerant Type | R290 / R507 Can be modified according to needs |
| Panel Thickness | 100mm, 200mm, 120mm, 75mm, 150mm |
| foaming | cyclopentane |
| Refrigeration Type | Self-Contained |
| Material | Stainless Steel/ Painted Steel |
| temperature control | Electronic temperature controller with display |
| Adjustable Set Point Range | -22~15℃ |
| Factory Set Point | -18℃ |
| Lighting control | Exterior switch-activated interior LED lighting |
| Light type | Neutral white LED lighting |
| Doors type | Swinger Solid or Glass |
| Condensate treatment | Automatic condensate evaporation system |
| defrost | defrosting automatic |
| Certifications & Compliances | ISO9001、CE Can apply for local national standards |
