Basic parameters | |||
---|---|---|---|
产品类型 Type | 立式风幕柜 Refrigerated Multideck Cabinet | 产品型号 Model | SG16HD |
设计工况 Design condition | 3(25℃,60%RH) | 温度范围 Temperature range | H1(2~8℃) |
能效等级 Energy Efficiency Grade | 3 | 制冷方式 Refrigerating system | 风冷 Air-Cooling |
长(mm) Width | 2080 ☑ custom | 宽/深(L)Depth | 2006 ☑ custom |
高(mm) Height | 1550 ☑ custom | 有效容积(L)Effective Volume | - |
柜体参数 Cabinet parameters | |||
柜体/颜色 Cabinet /color | 黑/白/灰 Black / White / grey ☑ custom | 柜体外壳材料 External Cabinet material | 镀锌板 SGCC |
柜体内衬材料 Internal Cabinet material | 镀锌板 SGCC | 柜口高度(mm) front end heigth | 360 |
发泡料 foaming | 环戊烷 cyclopentane | 搁板 Inside shelf | 镀锌板 SGCC |
搁板标配 Pallets | 3 | 搁板承重 Pallet weight | 100KG/m² |
搁板承重 Pallet Bearing | 150KG/m² | 侧板 Side panel |
G:玻璃侧板 单面厚度23mm S:发泡侧板 单面厚度36mm G: Glass Side Plate Thickness 23 mm S: Foamed Side Plate Thickness 36 mm |
侧板玻璃丝印颜色 Silk Printing Color of Side Plate Glass | 银灰色 Silver gray | 玻璃 Glass | 中空镀膜玻璃 19mm LOW-E hollow glass |
底脚 Foot | 地脚螺栓+脚轮 Foundation bolt & Castor wheel | 夜帘 Night curtain | 减速夜帘 Deceleration curtain |
毛重(kg) Gross weight | 200KG/1000mm | ||
制冷系统 Refrigerating system | |||
压缩机 Compressor | 艾默生/松下 Emerson/Panasonic ☑ custom | 蒸发温度 Evap Temp ℃ | -10℃ |
制冷剂 Refrigerant | R404A | 制冷剂灌注量(g)Refrigerant charge | - |
蒸发器 Evaporators | 铜管铝翼翅片式 Copper Tube with aluminum fins | 冷凝器 Condenser | 铜管铝翼翅片式 Copper Tube with aluminum fins |
节流方式 Throttle modes | 膨胀阀 danfoss | 温度控制 Temperature control | 电子式 Electronic temperature controller |
除霜 Defrost | 定时自然除霜 Off-Cycle defrost | 融霜水处理 Defrost water treatment | 排水管 Drain pipe |
电气参数 Electric parameter | |||
冷凝风机 Condenser Fan motor | 根据机组配备 Depending on unit allocation | 蒸发风机 Evaporating fan | 依必安派特 EBM |
照明灯 Lighting Canopy & Shelf | LED白色 white 合明光电 X-union | 输入功率(W) Input Power | 288W |
电压插头 Plug | 16A | 电压 Plug | 220V/50HZ, 380V |
![]() |
