  • Description

型号

外型尺寸(**高)

柜内温度()

额定电压

制冷剂

整机功率(w)

RDG-1000CF-1

1000*1000*1300

4~10

220V/50Hz

R134a/R22

980

RDG-1200CF-1

1200*1000*1300

4~10

220V/50Hz

R134a/R22

1150

RDG-1500CF-1

1500*1000*1300

4~10

220V/50Hz

R134a/R22

1300

RDG-1800CF-1

1800*1000*1300

4~10

220V/50Hz

R134a/R22

1500


产品主要性能介绍:

1、采用原装SECOP(思科普)压缩机(原丹佛斯Danfoss),静音稳定运行(静音设计)。
2、微电脑温度控制器、能准确控制柜内温度,带温度显示(柜外背面)。
3、采用风冷循环制冷,加厚紫铜管制冷系统,经久耐用。
4、正面,两侧面采用单层超白玻璃。
5、主体能见面均采用201#不锈钢材质,不锈钢螺丝,柜内能见面均为镜面不锈钢。
6、开放式展示,存取食物更显方便,一层展示。
7、每层配灯光,均采用LED灯管,灯管的颜色为暖白色,安全耐用。
8、冷藏温度范围:+4~+10℃,用户可根据实际需要调节使用温度范围。
9、底座为天然大理石装饰,颜色有:黑金砂、印度红、金线米黄、凤凰玉白色和紫罗红等可供选择。
10、底部自带活动轮,方便移动。
注意:开放式冷柜使用环境温度不得高于+25℃,风速不得大于每秒0.3秒,湿度不得高于60%!





Industrial products

1、Using original SECOP (Cisco Popular) compressor (original Danfoss), mute stable operation (mute design)。
2、The microcomputer temperature controller can accurately control the temperature inside the cabinet and display the temperature (outside the back of the cabinet).
3、Air cooled cycle refrigeration, thickened copper tube refrigeration system, durable。
4、Front arc glass adopts automatic electrothermal demister double hollow glass, which can automatically eliminate the water mist on the glass surface and ensure a better display effect; the side adopts hollow insulating transparent glass.。
5、201# stainless steel, stainless steel screws, and stainless steel can be used to meet the main body.。
6、The sliding door adopts hollow heat preservation transparent glass, and the surrounding rail adopts aluminum alloy profile (no fog proof function).。
7、Each floor is equipped with LED lights. The color of the tube is warm white. It is durable and safe.。
8、Refrigerating temperature range: +2 ~ +10 C, users can adjust the temperature range according to actual needs.。
9、On the second floor, the support of the frame is made of stainless steel with height adjusting holes. The height is adjustable (adjusting height is about 10 mm per knot). The frame is made of aluminum alloy, which is beautiful and generous.。
10、The base is decorated with natural marble. The colors are black gold sand, Indian red, golden thread beige, Phoenix jade white and violet red.。
11、Moving wheels at the bottom to facilitate movement. 。
