| ACR/AFR | Unit | N |
|---|---|---|
| Width | mm | 705*N+200(N=Glass door amount ) |
| Deep | mm | 1800~2200 |
| Height | mm | 2200~2800 |
| Panel thickness | mm | 75/100/120/150 |
| Door amount | N | |
| De-fogging type | Anti-fog with LOW-E tempered glass | |
| Glass door | 2to+10°C | 2 layer tempered glass door with electrical heating wire |
| Glass door | -1810-22°C | 3 layer tempered glass door with electrical heating wire |
| Glass door frame | Pure aluminurm with electncal heating wire | |
| Exterior&Interior | Colored powder-coated steel plate | |
| Defrost type | Auto defrost | |
| Water dryer | Extemal water pipe | |
| Evaporator | Copper tube fin | |
| Thermostat | Digital controller | |
| Compressor | Copeland /Sanyo/Bitzer | |
| Shelves style | Gnd/Solid | |
| Door open type | Hinge door/Swing door /Sliding door |
| SPECIFICATION | CONTENT |
|---|---|
| rated voltage： | 220 V~240V / 50 Hz Customizable 110V~240V/50-60HZ |
| Power Plug/Cord Length | 16A、3M |
| Refrigerating system | Air-Cooling |
| Compressor brand | Cubigel Can be modified according to needs |
| Core Components | Refrigeration Units |
| Refrigerant Type | R290 / R507 Can be modified according to needs |
| Panel Thickness | 100mm, 200mm, 120mm, 75mm, 150mm |
| foaming | cyclopentane |
| Refrigeration Type | Self-Contained |
| Material | Stainless Steel/ Painted Steel |
| temperature control | Electronic temperature controller with display |
| Adjustable Set Point Range | -22~15℃ |
| Factory Set Point | -18℃ |
| Lighting control | Exterior switch-activated interior LED lighting |
| Light type | Neutral white LED lighting |
| Doors type | Swinger Solid or Glass |
| Condensate treatment | Automatic condensate evaporation system |
| defrost | defrosting automatic |
| Certifications & Compliances | ISO9001、CE Can apply for local national standards |
